Application areas: air conditioning drainage pumps, coffee machines, water dispensers











GL2438-12A


Item
Specifications


Rated voltage (VDC)
12.0


Medium
water


No-load flow (ml/min)
550±10%


Current(mA)
＜200


Pressure (Kpa)
＞200


Noise (dB)
＜ 40dB/30cm


Application areas: air conditioning drainage pumps, coffee machines, water dispensers











GL2438-12B


Item
Specifications


Rated voltage (VDC)
12.0


Medium
water


No-load flow (ml/min)
500±10%


Current (mA)
＜100


Pressure (Kpa)
＞200


Noise (dB)
＜ 55dB/30cm

Application areas: sweeping robots, beauty instruments, portable coffee machines







GL030-5A


Item
Specifications


Rated voltage (VDC)
5.0


Medium water
water


No-load flow (ml/min)
40 ~ 90 (can be customized)


Current (mA)
＜100


Pressure(Kpa)
＞40


Noise (dB)
＜ 45dB/30cm

 Application areas: desktop coffee machines, wall-mounted water dispensers











GL2438-12F


Item
Specifications


Rated voltage (VDC)
12.0


Medium
water


No-load flow (ml/min)
1200±5%



Current (mA)
＜300


Pressure (Kpa)
＞200


Noise (dB)
＜ 55dB/30cm

 Application areas: American coffee machines, water dispensers











GL2438-12H


Item
Specifications


Rated voltage (VDC)
12.0


Medium
water


No-load flow (ml/min)
500~1500 (1.5L)


Current (mA)
＜200~400


Pressure (Kpa)
＞200


Noise (dB)
＜ 55dB/30cm

Application areas: scraping instrument, baby nasal aspirator







GL2438-3A


Item
Specifications


Rated voltage (VDC)
3.0


Medium
air


No-load flow (ml/min)
≥2.0


No-load current (mA)
≤1600


Vacuum degree (Kpa)
≤-65


Noise (dB)
≤ 55dB/30cm

Application areas: gas masks







GL3402-5A


Item
Specifications


Rated voltage (VDC)
5.0


Medium
air


No-load flow (ml/min)
＜900


No-load current (mA)
＜200


Pressure(Kpa)
＞30


Inflation time
100cc/15s


Noise (dB)
＜65dB/30cm


Application areas: PM2.5 air detector









GL1730-6A


Item
Specifications


Rated voltage (VDC)
6.0


Medium
air


No-load flow (ml/min)
280~350


No-load current (mA)
＜32


Pressure(Kpa)
＞28


Inflation time
50cc/10s


Noise (dB)
＜60dB/30cm

Long life

Lumbar support air pump: car lumbar support, massage, car neck brace, etc..

Applicable hoses: 2*1(ID2*OD4) 3*1(ID3*OD5) 4*1(ID4*OD6)

Applicable hose: #16 #25 #17
